WMA-3312 uPVC Window Single-head Variable-angle Welding Machine
Features and functions:
1. The machine is made up of machine head, machine frame, electric controlling box and supporting shelf etc.
2. There are orientating mechanism, pressing mechanism and heating mechanism etc.
3. This machine is used for PVC door and window welding processing with variable angle ranging from 30 degree to 180 degree.
4. It features PLC control, pneumatic driving, reliable function, simple operation and convenient maintenance.
Technical parameter:
|
Input voltage |
220V |
|
Input frequency |
50Hz |
|
Input power |
1.2kW |
|
Working air pressure |
0.5-0.8MPa |
|
Air consumption |
50L/ min |
|
Welding height |
20~120mm |
|
Max welding width |
120mm |
|
Max cutting size of profile welded |
330mm |
|
Dimension |
960 x 900 x 1460mm |
|
Net weight |
260kg |
